Model 1550
- 1978 bis 1980 -
Informationsquelle: Marantz-Prospekt von 1980 / Information source: Marantz brochure from 1980

VERSTÄRKERTEIL
AMPLIFIER SECTION

Nennleistung pro Kanal an 8 Ohm (FTC) 20 Hz - 20 kHz
Rated Power Output 8 Ohms (FTC) 20 Hz - 20 kHz

50 Watt

Klirrfaktor bei Nennleistung
Total Harmonic Distortion

0,15 %

Frequenzgang
Power Bandwidth

keine Angabe / unspecified



VORVERSTÄRKERTEIL
PREAMPLIFIER SECTION

Dynamikbereich
Dynamic Range

keine Angabe / unspecified

Frequenzgang (Phono)
Frequency Response (Phono)

RIAA +/- 1 dB

Signal-/Rauschspannungsabstand (Phono)
Signal to Noise Ratio (Phono)

72 dB



UKW TUNERTEIL
FM TUNER SECTION

Empfindlichkeit, stereo (DIN)
Sensitivity, stereo (DIN)

25 uV

Selektivität (98 MHz +/- 300 kHz)
Selectivity (98 MHz +/- 300 kHz)

65 dB

Frequenzgang
Frequency Response

keine Angabe / unspecified

Gesamtklirrfaktor mono / stereo
Total Harmonic Distortion mono / stereo

keine Angabe / unspecified

Stereotrennschärfe bei 1 kHz
Stereo Seperation at 1 kHz

keine Angabe / unspecified

Signal/Rauschabstand (98 MHz) mono / stereo, bewertet
Signal to Noise Ratio (98 MHz) mono / stereo, rated

66 dB

60 dB

Spiegelfrequenz-Unterdrückung
Image Rejection

keine Angabe / unspecified

Zwischenfrequenz-Unterdrückung
IF Rejection

keine Angabe / unspecified



ALLGEMEINE DATEN
GENERAL SPECIFICATIONS

Leistungsaufnahme bei Nennleistung
Power Consumptionat at rated output

keine Angabe / unspecified

Leistungsaufnahme im Leerlauf
Idling Power

keine Angabe / unspecified

Abmessungen (B x H x T)
Dimensions (W x H x D)

440 x 137 x 358 mm
17
1/4 x 5 3/8 x 14 1/3 inches

Gewicht
Weight

12,0 kg
26,4 lbs.

Geeignetes Woodcase
Matching Woodcase

WCV-115

Alle Angaben ohne Gewähr / All information without guarantee

.
