Model 5010B
- 1977 - 1978 -
Informationsquelle: / Information source: Marantz-Prospekt 1977 / Marantz brochure 1977 + audioarchieves.net

Gleichlaufschwankungen
Wow and Flutter

0,15% (DIN)

Frequenzgang Normalband:
Frequncy Response Normal:

30Hz-15kHz

Frequenzgang CrO2:
Frequncy Response CrO2:

30Hz-15,5kHz

Frequenzgang FeCr:
Frequncy Response FeCr:

30Hz-17kHz

Frequenzgang Reineisen:
Frequncy Response Metal:

./.

Fremdspannungsabstand:
Signal to Noise Ratio:

50 dB Dolby aus/off   -    58 dB Dolby an/on

Abmessungen (B x H x T)
Dimensions (W x H x D)

416 x 146 x 297 mm
16
1/2 x 5 3/4 x 11 11/16 inches16 7/8 x 5 x 14 inches

Gewicht
Weight

6,7 kg
14,75 lbs.36 lbs.

Alle Angaben ohne Gewähr / All information without guarantee

.
