Marantz 5030
.
Technical Specifications from Marantz Brochure 1978
Technische Daten aus Marantz-Prospekt 1978

Marantz 5030  -  vintage-marantz.com
Marantz 5030  -  vintage-marantz.com

Model 5030
- 1977 - 1979 -
Informationsquelle: / Information source: Marantz-Prospekt 1978 / Marantz brochure 1978 + audioarchieves.net

Gleichlaufschwankungen
Wow and Flutter

0,13% (DIN)

Frequenzgang Normalband:
Frequncy Response Normal:

25Hz-16kHz

Frequenzgang CrO2:
Frequncy Response CrO2:

25Hz-17,5kHz

Frequenzgang FeCr:
Frequncy Response FeCr:

20Hz-18kHz

Frequenzgang Reineisen:
Frequncy Response Metal:

./.

Fremdspannungsabstand:
Signal to Noise Ratio:

52 dB Dolby aus/off   -    60 dB Dolby an/on

Abmessungen (B x H x T)
Dimensions (W x H x D)

440 x 146 x 297 mm
17
3/8 x 5 3/4 x 11 11/16 inches16 7/8 x 5 x 14 inches

Gewicht
Weight

6,7 kg
14,75 lbs.36 lbs.

Alle Angaben ohne Gewähr / All information without guarantee

.
